FRP C Channel
Fiberglass Pultruded C Channel Profiles are fiberglass reinforced plastic products of constant cross section that are continuously formed by high temperature heating with reinforcing materials.
Product Performance Introduction
Fiberglass Pultruded C Channel Profiles are fiberglass reinforced plastic products of constant cross section that are continuously formed by high temperature heating with reinforcing materials: glass fiber roving, continuous mats, stitched mats, surface mats, and other matrix materials such as unsaturated polyester resins and polyurethane.
Excellent Corrosion & Weather Resistance
In many structural applications where wood would be subject to rot and metal to rust the pultruded products can last indefinitely, with little or no maintenance.
Light Weight with High Strength
The profiles will weigh 25% of the weight of the steel and 77% of aluminium.
Low Temperature Capabilities
The pultruded products have very low thermal conductive properties and in high or low temperatures do not expand or contract like metals.
Easy to Work
Pultruded materials are easily worked using traditional carpentry tools with carbon or diamond blades. The fiberglass materials are lightweight, and consequently easy to mount and install.
Profile Dimension Map
Cross-sectional analysis of the C Channel profile showing the relationship between width (A), height (B) and flange (c).
Pultrusion Accuracy
Our precision pultrusion dies ensure consistent dimensions across infinite lengths, maintaining structural integrity.
FRP C Channel Specification
| Size A*B*C (MM) | Weight (G/M) |
|---|---|
| 65*46*4 | 1648 |
| 90*50*4 | 2112 |
| 41*29*3.5 (double C) | 882 |
| 60*50*4 (double C) | 1632 |
| 100*38*3.5 | 1150 |
| 75*15*5 | 920 |
Need Custom C Channel Profiles?
We can provide custom profiles based on your specific engineering load requirements.
