SMC PRODUCTION

SMC Sheet Production

Alita operates a self-designed 1.25m wide fully automated SMC production line, combining proprietary high-performance resins with premium glass fibers to provide the most stable prepreg sheets for downstream molding.

Fully Automated Line

Stable Formulation

Multi-layer Composite

PRODUCTION WORKFLOW

SMC Production Workflow

From raw materials to finished products, 6 precision stages ensure the stability of every roll.

Film Laying

Automated laying of high-strength PE film to provide a stable carrier for resin coating.

Resin Coating

Precision metering system applies resin paste evenly, with thickness controlled at ±0.05mm.

Fiber Settlement

Chopping blades cut fiber into 25-50mm segments and settle them evenly onto the resin layer.

Roller Wetting

Multiple groups of wetting rollers apply pressure to force resin into every fiber filament.

Composite Winding

Top and bottom film layers composite with fiber to form a sandwich structure and auto-wind.

Constant Temp Curing

48-72 hours of reaction in a maturation room to reach optimal molding viscosity.

Wetting & Physical Compositing

The core of SMC sheet lies in 'wetting'. Alita's line is equipped with multiple sets of progressive wetting rollers, through precision adjustment of line pressure to force resin paste between fiber filaments.

Precise Fiber Content: Electronic weighing system monitors fiber proportion in real-time (25%-50%).
No Air Inclusion: Negative pressure induction technology ensures no residual bubbles during physical compression.
Customizable: Options for continuous mat reinforcement or local fabric reinforcement.

SPECIFICATION CATALOGUE

Full SMC Specification Catalogue

Click to switch categories and view precise physical/chemical parameters and industrial application notes.

General Purpose SMC Series

Covering a wide range from construction water tanks to general automotive parts, balancing processability and physical properties.

MODEL1028

Application / Notes

Average surface, suitable for ordinary products

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.15 %

Fiber: 21±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 130 Mpa

Flexural Modulus: 9 Gpa

Impact Strength: 45 KJ/m²

Tensile Strength: 50 Mpa

MODEL1039

Application / Notes

Good surface, general purpose

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.15 %

Fiber: 26±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 150 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 60 KJ/m²

Tensile Strength: 65 Mpa

MODEL1040

Application / Notes

Class A surface, suitable for sanitary products

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.10 %

Fiber: 26±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 150 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 55 KJ/m²

Tensile Strength: 60 Mpa

MODEL1045

Application / Notes

Average surface, suitable for ordinary products

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.15 %

Fiber: 19±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 110 Mpa

Flexural Modulus: 9 Gpa

Impact Strength: 40 KJ/m²

Tensile Strength: 45 Mpa

MODEL1045DC

Application / Notes

Good surface, suitable for meter boxes

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.15 %

Fiber: 21±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 130 Mpa

Flexural Modulus: 9 Gpa

Impact Strength: 45 KJ/m²

Tensile Strength: 50 Mpa

MODEL1046

Application / Notes

Slightly lower strength, for general automotive parts

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.15 %

Fiber: 26±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 150 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 60 KJ/m²

Tensile Strength: 65 Mpa

MODEL1046A

Application / Notes

Good surface, high strength, water resistant, for large tanks

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.12 %

Fiber: 32±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 170 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 65 KJ/m²

Tensile Strength: 70 Mpa

MODEL1081

Application / Notes

High strength, for automotive industry

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.12 %

Fiber: 28±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 160 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 65 KJ/m²

Tensile Strength: 70 Mpa

MODEL1081R

Application / Notes

High strength, good surface, for colored automotive exteriors

Physical Properties

Density: 1.75-1.85

Shrinkage: ≤0.12 %

Fiber: 30±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 170 Mpa

Flexural Modulus: 10 Gpa

Impact Strength: 75 KJ/m²

Tensile Strength: 80 Mpa

MODEL1081TX

Application / Notes

High strength, for large parts in automotive and other fields

Physical Properties

Density: 1.80-1.90

Shrinkage: ≤0.10 %

Fiber: 36±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 190 Mpa

Flexural Modulus: 11 Gpa

Impact Strength: 85 KJ/m²

Tensile Strength: 90 Mpa

MODEL1086

Application / Notes

High strength, average surface, for high-frequency vibration parts

Physical Properties

Density: 1.80-1.90

Shrinkage: ≤0.10 %

Fiber: 38±2 %

Water Abs: ≤20 mg

Mechanical Properties

Flexural Strength: 200 Mpa

Flexural Modulus: 11 Gpa

Impact Strength: 95 KJ/m²

Tensile Strength: 100 Mpa

QUALITY CONTROL

Constant Temp Storage & Maturation

SMC is an 'active' semi-finished product. We are equipped with modern maturation rooms and cold storage (15-20℃) to ensure optimal viscosity before molding.

Full Cold Chain

Storage and transport recommended below 25℃, away from light.

3-6 Months Shelf Life

Providing long and stable storage cycles through optimized resin systems.

More Than Just Selling Sheets

We provide one-stop SMC solutions from resin customization to sheet production and mold parameter tuning.
